5FCM管状保险丝
| 分类 | 管式保险丝 |
| SKU | |
| 单位 |
产品详情
厂家长期供应引线汽车保险丝座、保险丝、汽车保险丝座、汽车保险丝盒、保险丝座、汽车保险丝座、玻璃保险丝等
Time-Lag High Breaking Capacity (φ5*20MM)
+Approvals(5FLM)
SEMKO 1A-6.3A VDE 500mA-12A BSI 1A-6.3mA
UL Recongnized 500mA-10A CSA Acceptance 500mA-10A
PSE 1A-12A KTL 1A-6.3A CCC 1A-6.3A CQC 8A/10A
+Interrupting Ratings
1500 amperes at 250V AC.
Electrical Characteristics
| Rated Current | 1.5 In | 2.1 In | 2.75 In | 4 In | 10 In | |||
| MIN | MAX | MIN | MAX | MIN | MAX | MIN | MAX | |
| 500mA~3.15A | 60min | 30min | 250ms | 80ms | 50ms | 5ms | 5ms | 150ms |
| 4mA~6.3A | 60min | 30min | 750ms | 80ms | 95ms | 5ms | 10ms | 150ms |
| 80mA~12A | 30min | 30min | 750ms | 80ms | 150ms | 5ms | 10ms | 150ms |
+Operating Temperature -55℃ to +125℃
| Cartidge Catalog Number | Ampere Rating | Voltage Rating | Nominal Resistance | Valtage Drop Mel | Nominal Ting L2f |
| (In) | (V) | Cold Ohms | (Mv)MAX | A.Sec | |
| 5FCM .500 | 500mA |
250V |
0.2540 | 300 | 0.60000 |
| 5FCM .630 | 630mA | 0.1430 | 280 | 1.44900 | |
| 5FCM .800 | 800mA | 0.1180 | 250 | 2.56000 | |
| 5FCM 001 | 1A | 0.0730 | 250 | 2.00000 | |
| 5FCM 1.25 | 1.25A | 0.0690 | 250 | 1.86100 | |
| 5FCM 1.60 | 1.6A | 0.0670 | 200 | 3.32800 | |
| 5FCM 002 | 2A | 0.0580 | 190 | 7.70000 | |
| 5FCM 2.50 | 2.5A | 0.3950 | 180 | 11.2000 | |
| 5FCM 3.15 | 3.15A | 0.0289 | 140 | 19.9100 | |
| 5FCM 004 | 4A | 0.0192 | 100 | 38.4000 | |
| 5FCM 005 | 5A | 0.0153 | 100 | 70.0000 | |
| 5FCM 6.30 | 6.3A | 0.0114 | 100 | 158.700 | |
| 5FCM 008 | 8A | 0.0073 | 100 | 288.000 | |
| 5FCM 010 | 10A | 0.0057 | 100 | 490.000 | |
| 5FCM 012 | 12A | 0.0037 | 100 | 1080.00 |
