SBAF-MF 20A-100A 32Vdc
| 分类 | 方型慢断汽车保险丝 |
| SKU | 5000 |
| 单位 | PCS |
产品详情
- 方型慢熔保险丝 | Square Shape Slow melting Fuse
- 型号 | model:SBAF-MF
- 慢熔|Slow melting
- 安规认证|Safety certificatio
Ps：According to usage conditions, the characteristics of the fuse may change|根据使用狀況，保险丝特性可能改变！
- 1.SBAF-MF is a cartridge style fuse with female terminal design. JCASE® provides both increased time delay and low voltage drop to protect high current circuits. JCASE® has the ability to handle inrush currents.
- 1.SBAF-MF是带连接座/头和端子的管状保险丝，它既增加了延时，又降低了电压降，可保护高电流电路并能应对突入电流
- 2.Note
- Voltage Rating: 32 VDC
- Interrupting Rating: 1000A amperes at32 VDC
- Operating Temperature Range: -40˚ C to + 125˚ C
- Housing Material:
- Housing Material (60A):
- Cover Material:
- Insertion Force:
- Extraction Force:
- Complies with:
- 2.注额定电压：32vdc
- 中断额定值：32vdc时1000A安培
- 工作温度范围：-40˚C~ 125˚C
- 外壳材料：
- 外壳材料（60A）：
- 外壳材料：
- 插入力：
- 拔出力：
- 符合：
- 3.The specifications and models of fuses are as follows|保险丝规格型
| Material number |
Ampere rating |
Volt |
Color |
Typ. Voltage Drop (mV) |
I²t (A²s) |
| SBAF-MF20A | 20 | 32V DC |
Lt.Blue
|
||
|
SBAF-MF30A |
30 |
Pink
|
|||
|
SBAF-MF40A |
40 |
Green
|
|||
|
SBAF-MF50A |
50 |
Red
|
|||
|
SBAF-MF60A |
60 |
Yellow
|
|||
|
SBAF-MF70A |
70 |
Brown
|
|||
| SBAF-MF80A | 80 |
Black
|
|||
| SBAF-MF100A | 100 |
Blue
|
- 4.Fusing characteristics|熔断特性
|
In
|
1.1In
|
2.0In
|
3.5In
|
6.0In
|
|||
|
20-100A
|
>4 Hours
|
Min |
Max |
Min |
Max |
Min |
Max |
|
5 s
|
100 s
|
0.2 s
|
7 s
|
0.04 s
|
1 s
| ||
注notes:
@环保文件以附件发送，每年更新一次;
@Environmental protection documents shall be sent as attachments and updated once a yea
@安规证书附件发送
@Attachment of safety regulation certificate
