WG-H1M7S 多路螺栓保险丝盒
- 2025-03-31 11:10:19
- 0
多路螺栓保险丝盒 | Bolt plate fuse Box Multipoint wiring
型号 | model: WG-H1M7S
1.The WG-H1M7S fuse box is an internal bus fuse holder with waterproof effect. It can be customized according to customer requirements, offering either one-in-multiple-out or two-in-multiple-out wiring methods.
1.WG-H1M7S保险丝盒是一款内部总线且具有防水效果 的保险丝座，可根据客户需求可选择一进多出或二进多出接线方式
2.Ordering Information
| Ampere (A) |
500 AMP MAX |
| Applicable Fuse |
ANMA/AN998/AN498 /AN478/AN492 |
| Voltage |
≤70V DC |
| Operating Temp |
-40～+125℃ |
| Wiring method |
1 input with 7 outputs (N ≤ 7) |
3.注notes：
@环保文件以附件发送，每年更新一次；
@Environmental protection documents shall be sent as attachments and updated once a yea
@安规证书附件发送
@Attachment of safety regulation certificate
@需要详细规格书请联系我们|Please contact us if you need the detailed specification sheet.
