AN491xxx40-120A
- 2026-02-26 16:52:00
- 0
螺栓保险丝|Bolt FUSE
型号|model: AN491 40-150A
慢熔|Slow melting
安规认证|Safety certificatio
1.The AN491xxxFuse is designed for high current circuit protection up to 150A with “DiffusionPill Technology.” AN491xxxFuse also provides time delay characteristics. the ANMZ Fuse is ideal for battery and alternator protection application and other heavy gauge cables requiring ultra-high current protection.
1.AN491xxx保险丝设计用于高达150A的大电流电路保护,高分断技术”。 AN491xxx熔断器还提供延时特性。 AN491xxx保险丝是理想的电池以及交流发电机保护应用和其他需要超高电流的大规格电缆保护。
2.Ordering Information
| Part Number |
Ampere (A) |
Voltage (VDC/VAC) |
Body Color |
| AN491040 |
40A | 60VDC | Silvery |
| AN491050 |
50A | ||
| AN491060 |
60A | ||
| AN491070 |
70A | ||
| AN491080 |
80A | ||
| AN491100 |
100A | ||
| AN491110 |
110A | ||
| AN491120 |
120A |
3.注notes：
@环保文件以附件发送，每年更新一次；
@Environmental protection documents shall be sent as attachments and updated once a yea
@安规证书附件发送
@Attachment of safety regulation certificate
@需要详细规格书请联系我们|Please contact us if you need the detailed specification sheet.
