WGP28 32V/58V 1A-40A

  • 2025-05-09 08:50:29
  • 0
  1. 小型保险丝座 | Small fuse holder

    1. 型号 | model:  WGP28
    2. 安装方式   | nstallation method   : PCB波峰焊| PCB wave soldering


    1. Specifications | 规范
      Brand:WOGEFUSE
      Fuse Hardware: AB11U/AB11N/297/997 Auto Fuses
      Available Fuse Rating: 1A-40A
      Max Voltage: 32V.dc
      Max Fuse Rating: 30A
      Operating Temp: - 25 ° ~ 1 2 5° C
      Flame retardant grade: UL-94V0
      Withstand voltage: 1000V
      Practical scope: instrument, ship, Chong New Energy Vehicle Assembly, mobile power supply, energy storage battery, car battery, car audio RV modification
      Note: If there is no notification of product size changes, please contact the sales consultant;

  • Specifications | 规范
    品牌 :沃格精密
    适用保险丝: AB11U/AB11N/297/997 汽车保险丝
    可用保险丝额定值: 1A-40A
    最大电压: 32V直流
    最大保险丝额定值: 20A
    工作温度: -25°~125°C
    阻燃等级:UL-94V0
    耐压:1000V
    实用范围:仪器、船舶、崇新能源汽车总成、移动电源、储能电池、汽车电池、汽车音响RV改装
    注:未通知产品尺寸变化 , 请联系销售顾问 ;

    1. 注notes:
      @环保文件以附件发送,每年更新一次;
      @Environmental protection documents shall be sent as attachments and updated once a year;
      @安规证书附件发送;
      @Attachment of safety regulation certificate
