1206 250mA-30A 72/63/32Vdc慢熔|Slow melting
- 2022-08-06 19:17:19
- 0
贴片保险丝|SMD Fuses 型号|model:1206 250mA-30A 72/63/32Vdc Rohs
@速熔|Rapid melting
@慢熔|Slow melting
1206(0.126x0.063x0.0256mm) 63Vdc/32Vdc 250mA-30A
Dimensions(mm)
Description
The 1206 Series are the fuses set the industry standard for performance, reliability and quality. The solder-free design provides excellent on-off and temperature cycling characteristics during use and also makes our SMD fuses more heat and shock tolerant than typical subminiature fuses.
| alog Symbol | Size | Rated Voltage(V) | Ampere Range | Dimensions | Material | Class of operation | |
| AC | DC | (LxWxH mm) | |||||
| 12 | 1206 | / | 125/72/63/32 | 1A~30A | 3.2*1.6*0.65mm | Body: Ceramic | FAST ACTING |
| Terminal: Silver over-plated with tin | |||||||
| 12.1 | 1206 | / | 125/72/63/32 | 250mA~30A | 3.2*1.6*0.65mm | Body: Ceramic | SLOW BLOW |
| Terminal: Silver over-plated with tin | |||||||
Applications
Secondary circuit protection; Laptop, notebook, netbook; Flat panel displays; High-definition television (HDTV); LCD/LED backlighting; Computers and peripherals; Automotive; Central body control module; Heating ventilation and air conditioning; Doors, window lift and seat control; Digital instrument cluster; In-vehicle infotainment and navigation; Electric pumps, motor control and powertrain control; Module(PCU)/Engine; Gaming console systems; Handheld/portable equipment; Mobile device charges.
