1206  1A-30A  72/63/32Vdc速熔|Rapid melting

  • 2022-08-06 19:18:08
  • 0

贴片保险丝|SMD Fuses  型号|model:1206  1A-30A  72/63/32Vdc   Rohs
@速熔|Rapid melting

@慢熔|Slow melting


1206(0.126x0.063x0.0256mm) 63Vdc/32Vdc 250mA-30A

Dimensions(mm)



Description

The 1206 Series are the fuses set the industry standard for performance, reliability and quality. The solder-free design provides excellent on-off and temperature cycling characteristics during use and also makes our SMD fuses more heat and shock tolerant than typical subminiature fuses.

alog Symbol Size Rated Voltage(V) Ampere Range  Dimensions Material Class of operation
AC DC     (LxWxH mm)
12 1206 / 125/72/63/32 1A~30A 3.2*1.6*0.65mm Body: Ceramic FAST ACTING
Terminal: Silver over-plated with tin
12.1 1206 / 125/72/63/32 250mA~30A 3.2*1.6*0.65mm Body: Ceramic SLOW BLOW
Terminal: Silver over-plated with tin

Applications


Secondary circuit protection; Laptop, notebook, netbook; Flat panel displays; High-definition television (HDTV); LCD/LED backlighting; Computers and peripherals; Automotive; Central body control module; Heating ventilation and air conditioning; Doors, window lift and seat control; Digital instrument cluster; In-vehicle infotainment and navigation; Electric pumps, motor control and powertrain control; Module(PCU)/Engine; Gaming console systems; Handheld/portable equipment; Mobile device charges.
