ANC-K 20-500A 32V
- 2025-05-12 10:11:59
- 0
- 螺栓保险丝|Bolt FUSE
- 型号|model: ANMG
- 慢熔|Slow melting
- 安规认证|Safety certificatio
- Ps：According to usage conditions, the characteristics of the fuse may change|根据使用狀況，保险丝特性可能改变
- 1.The ANC-K Fuse is designed for high current circuit protection up to 500A witH “DiffusionPill Technology”ANC- K Fuse also provides time delay characteristics. the ANC Fuse is ideal for battery and alternator protection application and other heavy gauge cables requiring ultra-high current protection.
- 1.ANC-K保险丝设计用于高达500A的大电流电路保护，采用“高分断技术”ANC- K保险丝还提供延时特性。ANC保险丝是理想的电池和交流发电机保护应用和其他需要超高电流保护的大规格电缆。
2.Note
- Rated voltage: less than 32VDC
- Breaking capacity: 2000 amperes at 32 Vdc
- Operating temperature: -40 ℃~+125 ℃
- Execution standard: ISO8820-5
- Material: Cu/ NickeI
- 2.说明
- 额定电压：小于直流32VDC
- 致断容量：32vdc时2000安培
- 使用温度：-40℃～+125℃
- 执行标准：ISO8820-5
- 材质：铜/镍
3.The specifications and models of fuses are as follows|保险丝规格型号
| Material number |
Ampere rating |
Color |
Volt |
Safety regulations |
| ANC020.K |
20 | Black | 32V DC | / |
| ANC025.K |
25 | / | ||
| ANC030.K |
30 | / | ||
| ANC040.K |
40 | / | ||
| ANC050.K |
50 | / | ||
| ANC060.K |
60 | / | ||
| ANC070.K |
70 | / | ||
| ANC080.K |
80 | / | ||
| ANC100.K |
100 | / | ||
| ANC125.K |
125 | / | ||
| ANC150.K |
150 | / | ||
| ANC175.K |
175 | / | ||
| ANC200.K |
200 | / | ||
| ANC225.K |
225 | / | ||
| ANC250.K |
250 | / | ||
| ANC275.K |
275 | / | ||
| ANC300.K |
300 | / |
4.Fusing characteristics|熔断特性
| % of Ampere Rating |
Ampere Rating |
Opening Time |
| 110% | 20-500A | 4 Hours, Minimum |
| 150% | 20-500A |
3600 secMin- |
| 220% | 20-500A |
-S Min- 60S MAX |
| 250% | 20-500A |
0.8 sec.,Min;10 sec.,Max; |
| 400% | 20-500A |
0.2 sec.,Min;2 sec.,Max; |
注notes:
@环保文件以附件发送，每年更新一次;
@Environmental protection documents shall be sent as attachments and updated once a yea
@安规证书附件发送
@Attachment of safety regulation certificate
